Parker Denison F12-250-QF-SV-D-502-MUVR-PT Hydraulic Motor – 3720717

Series-specific model code

Original model: F12-250-QF-SV-D-502-MUVR-PT

Code coverage: Evidence-supported meanings shown. Confirmation required for remaining configuration.

Evidence profile: F12 field-level ordering-code profile (manual-evidence revision 6)

Code segment	Evidence-bound meaning
F12	Series: F12.
250	Documented displacement: 242.0 cm3/rev.
Q	Function code: Q. Contact us to confirm.
F	Main ports: SAE 6000 psi flange.
S	Mounting-flange code: S. Contact us to confirm.
V	Shaft seal: FPM for high pressure and high temperature.
D	Shaft: DIN spline.
502	Version number: 502 (manufacturer-assigned identifier for this version).
MUVR	Option 1: Make-up / anti-cavitation valve for clockwise rotation.
PT	Option 2: Prepared for speed sensor and painted black.

The series, frame and each supplied trailing field are kept separate. Documented values are decoded; legacy, special and table-dependent selections remain visible and say Contact us to confirm. Repair and spare-kit descriptions fail closed.
