Product Identification
| Brand | Parker Denison |
|---|---|
| Series | M4D Series |
| Order No | 02426152003 |
| Model | M4DC-138-67-3N03-B102 |
| Alternate models | M4DC 138 67 3N03 B102 |
| Also searched as | M4DC 138 67 3N03 B102 / 02426152003 / M4DC-138-67-3N03-B102 |
Parker Denison M4DC-138-67-3N03-B102 Hydraulic Motor – 02426152003
Order No. 02426152003 identifies this Parker Denison hydraulic motor in the M4D Series; the source model code is M4DC-138-67-3N03-B102.
BrandParker Denison
Order No02426152003
ModelM4DC-138-67-3N03-B102
Product NameParker Denison M4DC-138-67-3N03-B102 Hydraulic Motor – 02426152003
Product TypeHydraulic Motor
Alternate Model / Model 1M4DC 138 67 3N03 B102
SeriesM4D Series
Availability / Lead Time
Product Details
Product Overview
- Model M4DC-138-67-3N03-B102 appears under more than one record in the M4d Series. Use 02426152003 to distinguish this product entry.
- Alternate code M4DC 138 67 3N03 B102 is shown as an additional identification reference. It does not by itself confirm interchangeability.
Product Classification
| Product type | Hydraulic Motor |
|---|---|
| Documented displacement | 144.4 cm3/rev; second: 71.1 cm3/rev |
Series-specific model code
Original model: M4DC-138-67-3N03-B102
Code coverage: Evidence-supported selected code meanings identified.
Evidence profile: M4DC field-level ordering-code profile (manual-evidence revision 6)
| Code segment | Evidence-bound meaning |
|---|---|
M4DC |
Series: M4DC. |
138 |
Documented displacement: 144.4 cm3/rev. |
67 |
Second documented displacement: 71.1 cm3/rev. |
3 |
Shaft: Splined shaft (SAE C). |
N |
Direction of rotation: bi-directional. |
03 |
Porting combination: Catalogued double-motor porting combination 03. |
B |
Design level: B. |
1 |
Seal: S1 BUNA-N seal class. |
02 |
Ports: Four-bolt SAE flange with UNC threads and SAE drain. |
Each supplied shaft, direction, porting, design, seal, port and modification field remains separate. Catalog-backed values are decoded; unknown or historical selections remain unchanged and say Contact us to confirm.
Availability
Inquiry Only.
FAQ
Product FAQ
Is this the right record for my order number?
Use this record when the Order No or model code matches your nameplate. Send photos if the code is incomplete or written differently.
Can an alternate model code be used?
Yes, but the quote should still be checked against the primary order number and nameplate photo.
What should I send for quote review?
Send the complete order number, complete model code, nameplate photo when available, and required quantity.
