Product Identification
| Brand | Parker Denison |
|---|---|
| Series | M4SC Series |
| Order No | 024-93189-500 |
| Model | M4SC1-024-1N00-A504 |
| Alternate models | M4SC1 024 1N00 A504 |
| Also searched as | M4SC1 024 1N00 A504 / 024-93189-500 / 02493189500 / M4SC1-024-1N00-A504 |
Parker Denison M4SC1-024-1N00-A504 Hydraulic Motor – 024-93189-500
Order No. 024-93189-500 identifies this Parker Denison hydraulic motor in the M4SC Series; the source model code is M4SC1-024-1N00-A504.
BrandParker Denison
Order No024-93189-500
ModelM4SC1-024-1N00-A504
Product NameParker Denison M4SC1-024-1N00-A504 Hydraulic Motor – 024-93189-500
Product TypeHydraulic Motor
Alternate Model / Model 1M4SC1 024 1N00 A504
SeriesM4SC Series
Availability / Lead Time
Product Details
Product Overview
- Alternate code M4SC1 024 1N00 A504 is shown as an additional identification reference. It does not by itself confirm interchangeability.
Product Classification
| Product type | Hydraulic Motor |
|---|---|
| Documented displacement | 24.4 cm3/rev |
Series-specific model code
Original model: M4SC1-024-1N00-A504
Code coverage: Evidence-supported selected code meanings identified.
Evidence profile: M4SC1 field-level ordering-code profile (manual-evidence revision 6)
| Code segment | Evidence-bound meaning |
|---|---|
M4SC1 |
Series: M4SC1. |
024 |
Documented displacement: 24.4 cm3/rev. |
1 |
Shaft: Keyed shaft (SAE B). |
N |
Direction of rotation: bi-directional. |
00 |
Porting combination: Standard porting combination. |
A |
Design level: A. |
5 |
Seal: S5 fluorocarbon seal class. |
04 |
Ports: Four-bolt SAE flange with UNC threads and BSPP drain. |
Each supplied shaft, direction, porting, design, seal, port and modification field remains separate. Catalog-backed values are decoded; unknown or historical selections remain unchanged and say Contact us to confirm.
Availability
Inquiry Only.
FAQ
Product FAQ
Is this the right record for my order number?
Use this record when the Order No or model code matches your nameplate. Send photos if the code is incomplete or written differently.
Can an alternate model code be used?
Yes, but the quote should still be checked against the primary order number and nameplate photo.
What should I send for quote review?
Send the complete order number, complete model code, nameplate photo when available, and required quantity.
