Product Identification
| Brand | Parker Denison |
|---|---|
| Series | M4SD Series |
| Order No | 024-77949-500 |
| Model | M4SD-128-3N00-B504 |
| Alternate models | M4SD 128 3N00 B504 |
| Also searched as | M4SD 128 3N00 B504 / 024-77949-500 / 02477949500 / M4SD-128-3N00-B504 |
Parker Denison M4SD-128-3N00-B504 Hydraulic Motor – 024-77949-500
Order No. 024-77949-500 identifies this Parker Denison hydraulic motor in the M4SD Series; the source model code is M4SD-128-3N00-B504.
BrandParker Denison
Order No024-77949-500
ModelM4SD-128-3N00-B504
Product NameParker Denison M4SD-128-3N00-B504 Hydraulic Motor – 024-77949-500
Product TypeHydraulic Motor
Alternate Model / Model 1M4SD 128 3N00 B504
SeriesM4SD Series
Availability / Lead Time
Product Details
Product Overview
- Model M4SD-128-3N00-B504 appears under more than one record in the M4sd Series. Use 024-77949-500 to distinguish this product entry.
- Alternate code M4SD 128 3N00 B504 is shown as an additional identification reference. It does not by itself confirm interchangeability.
Product Classification
| Product type | Hydraulic Motor |
|---|---|
| Documented displacement | 132.4 cm3/rev |
Series-specific model code
Original model: M4SD-128-3N00-B504
Code coverage: Evidence-supported selected code meanings identified.
Evidence profile: M4SD field-level ordering-code profile (manual-evidence revision 6)
| Code segment | Evidence-bound meaning |
|---|---|
M4SD |
Series: M4SD. |
128 |
Documented displacement: 132.4 cm3/rev. |
3 |
Shaft: Splined shaft (SAE C). |
N |
Direction of rotation: bi-directional. |
00 |
Porting combination: Standard porting combination. |
B |
Design level: B. |
5 |
Seal: S5 fluorocarbon seal class. |
04 |
Ports: Four-bolt SAE flange with UNC threads and BSPP drain. |
Each supplied shaft, direction, porting, design, seal, port and modification field remains separate. Catalog-backed values are decoded; unknown or historical selections remain unchanged and say Contact us to confirm.
Availability
Inquiry Only.
FAQ
Product FAQ
Is this the right record for my order number?
Use this record when the Order No or model code matches your nameplate. Send photos if the code is incomplete or written differently.
Can an alternate model code be used?
Yes, but the quote should still be checked against the primary order number and nameplate photo.
What should I send for quote review?
Send the complete order number, complete model code, nameplate photo when available, and required quantity.
