Parker Denison T12-080-MT-CV-D-000-A-0-048/02 Hydraulic Motor – 3789749

Series-specific model code

Original model: T12-080-MT-CV-D-000-A-0-048/02

Code coverage: Evidence-supported meanings shown. Confirmation required for remaining configuration.

Evidence profile: T12 field-level ordering-code profile (manual-evidence revision 7)

Code segment	Evidence-bound meaning
T12	Series: T12.
080	Documented frame displacement: 80 cm3/rev.
M	Function: bi-directional motor.
T	Main ports: metric threads.
C	Mounting flange: cartridge flange.
V	Shaft seal: PPS selection.
D	Shaft end: Spline DIN 5480 shaft end.
000	Manufacturer-assigned serial or special-version number: 000. Contact us to confirm.
A	Manufacturer-assigned technical status: A. Contact us to confirm.
0	Speed-sensor selection: 0. Contact us to confirm.
048	Maximum displacement setting: 48 cm3/rev.
02	Minimum displacement setting: 2 cm3/rev.

T12 is routed independently from V12. The official T12 ordering page supports the leading frame, function, ports, mounting, shaft-seal, shaft-end and max/min displacement positions; manufacturer-assigned and control fields remain visible and require confirmation.
