Parker Denison P24P2R1E2N2A030 Hydraulic Pump – 023-08431-0

Series-specific model code

Original model: P24P2R1E2N2A030

Code coverage: Evidence-supported selected code meanings identified.

Evidence profile: Gold Cup pump field-by-field ordering-code profile (manual-evidence revision 6)

Code segment	Evidence-bound meaning
P	Unit: pump.
24	Documented displacement: 403 cm3/rev.
P	Type: Variable displacement, closed circuit pump.
2	Shaft: keyed SAE with mechanical seal.
R	Rotation: Clockwise (pump).
1	Seals: nitrile (Buna-N).
E	Design code: E (assigned by manufacturer).
2N	Primary control: three-position spring-centered electrohydraulic cylinder control.
2	Secondary control: volume indicator.
A	Control location: primary control on Port A side.
03	Control feature: CETOP3 NG6 valve, 110 VAC/60 Hz with wiring box.
0	Internal pump: 46 cm3/rev.

The parser uses longest-match field boundaries for displacement, optional efficiency, shaft and compact controls. Documented selected values are shown individually; unknown, truncated and extra selections remain visible and show Contact us to confirm. Omitted optional fields are not presented as selected defaults.
