Parker Denison P11P2R1C8A4A04M2 Hydraulic Pump – P11P-2R1C-8A2-A04-000

Series-specific model code

Original model: P11P2R1C8A4A04M2

Code coverage: Evidence-supported meanings shown. Contact us to confirm unresolved selections.

Evidence profile: Gold Cup pump field-by-field ordering-code profile (manual-evidence revision 6)

Code segment	Evidence-bound meaning
P	Unit: pump.
11	Documented displacement: 180 cm3/rev.
P	Type: Variable displacement, closed circuit pump.
2	Shaft: keyed SAE with mechanical seal.
R	Rotation: Clockwise (pump).
1	Seals: nitrile (Buna-N).
C	Design code: C (assigned by manufacturer).
8A	Primary control: hydraulic stroker with adjustable maximum volume stops.
4	Secondary control: torque limiter and volume indicator.
A	Control location: primary control on Port A side.
04	Control feature: 75-250 PSI.
M2	Contact us to confirm.

The parser uses longest-match field boundaries for displacement, optional efficiency, shaft and compact controls. Documented selected values are shown individually; unknown, truncated and extra selections remain visible and show Contact us to confirm. Omitted optional fields are not presented as selected defaults.
