Parker Denison T67DDCS-B35-B35-005-3L00-A501 Hydraulic Pump – 054-35228-5

Series-specific model code

Original model: T67DDCS-B35-B35-005-3L00-A501

Code coverage: Evidence-supported meanings shown. Confirmation required for remaining configuration.

Evidence profile: T67DDCS exact single/double/triple ordering-code profile (HY29-0001/UK evidence revision 6)

Code segment	Evidence-bound meaning
T67DDCS	Series: T67DDCS.
B35	Shaft-end pump core (D family) documented displacement: 113.4 cm3/rev.
B35	Centre pump core (D family) documented displacement: 113.4 cm3/rev.
005	Cover-end pump core (C family) displacement code: 005. Contact us to confirm.
3	Shaft code 3: splined SAE C shaft, 12/24 pitch, 14 teeth.
L	Rotation: left-hand (counter-clockwise), viewed from the shaft end.
00	Porting code: 00 (standard porting).
A	Design letter: A.
5	Seal code 5: S5 VITON seal class.
01	Connection/modification code: 01.

The exact longest series prefix determines the number and family of pump-core slots. Displacement codes are decoded only through the family table printed for that slot; identical codes are not generalized across A-AS, A-ASW, B, C, D or E cores. Shaft identity remains tied to the complete series. R/L is interpreted from the shaft-end view. Porting 00 is standard; other catalog-shaped porting codes are retained and require physical-orientation confirmation. Unsupported families and unknown special tails fail closed without blocking earlier evidence-supported fields.
