Parker Denison T6CC-22-6-5R03-C101 Hydraulic Pump – 024-26043-003

Series-specific model code

Original model: T6CC-22-6-5R03-C101

Code coverage: Evidence-supported meanings shown. Confirmation required for remaining configuration.

Evidence profile: T6CC exact single/double/triple ordering-code profile (HY29-0001/UK evidence revision 6)

Code segment	Evidence-bound meaning
T6CC	Series: T6CC.
22	Shaft-end pump core (C family) displacement code: 22. Contact us to confirm.
6	Cover-end pump core (C family) displacement code: 6. Contact us to confirm.
5	Shaft code 5: splined SAE B shaft, 13 teeth.
R	Rotation: right-hand (clockwise), viewed from the shaft end.
03	Two-character porting code preserved; physical port orientation: 03. Contact us to confirm.
C	Design letter: C.
1	Seal code 1: S1 BUNA N seal class.
01	Connection/modification code: 01.

The exact longest series prefix determines the number and family of pump-core slots. Displacement codes are decoded only through the family table printed for that slot; identical codes are not generalized across A-AS, A-ASW, B, C, D or E cores. Shaft identity remains tied to the complete series. R/L is interpreted from the shaft-end view. Porting 00 is standard; other catalog-shaped porting codes are retained and require physical-orientation confirmation. Unsupported families and unknown special tails fail closed without blocking earlier evidence-supported fields.
