Parker Denison T6ERM-085-3R03-C42-A1 Hydraulic Pump – 024-77189-0032

Series-specific model code

Original model: T6ERM-085-3R03-C42-A1

Code coverage: Evidence-supported meanings shown. Confirmation required for remaining configuration.

Evidence profile: T6ERM series-first T-family profile (manual-evidence revision 7)

Code segment	Evidence-bound meaning
T6ERM	Series code: T6ERM.
085	Pump core documented displacement: 268.7 cm3/rev.
3	T6ERM shaft code: 3. Contact us to confirm.
R	Rotation: right-hand (clockwise), viewed from the shaft end.
03	Porting code: 03. Contact us to confirm.
C	Design letter: C.
4	Seal code 4: EPDM seal class.
2	Remaining design, connection or modification selection: 2. Contact us to confirm.
A1	Control, connection, design or special trailing selection: A1. Contact us to confirm.

The source first segment is retained as the series code. Pump-core positions are recovered only when the shaft/rotation/porting boundary is structurally unambiguous; a documented family-local displacement table is then applied per core. An unknown series variant or option never prevents later independent fields from remaining visible.
