Product Identification
| Brand | Rexroth |
|---|---|
| Series | A17FO Series |
| Order No | R902250571 |
| Model | A17FO023/10NLWK0E81-0 |
| Also searched as | R902250571 / A17FO023/10NLWK0E81-0 |
Rexroth A17FO023/10NLWK0E81-0 Axial Piston Fixed Pump - R902250571
Rexroth A17FO Series 10 axial piston fixed pump for commercial-vehicle PTO applications. Model A17FO023/10NLWK0E81-0; order no. R902250571. Confirm the nameplate and operating requirements when requesting a quote.
BrandRexroth
Order NoR902250571
ModelA17FO023/10NLWK0E81-0
Product NameRexroth A17FO023/10NLWK0E81-0 Axial Piston Fixed Pump - R902250571
Product TypeAxial piston fixed pump
SeriesA17FO Series
Series ApplicationCommercial-vehicle high-pressure pump; PTO mounting context
Availability / Lead Time
Product Details
Product Overview
This HydroCatalog record identifies Rexroth Order No. R902250571, complete model A17FO023/10NLWK0E81-0, within A17FO Series 10. The complete model matches the approved Series 10 ordering pattern, and the code meanings below remain series-level ordering-code evidence rather than item-level operating confirmation. Check the full nameplate details before quote review.
Product Classification
| Product type | Axial piston fixed pump |
|---|---|
| Series Application | Commercial-vehicle high-pressure pump; PTO mounting context |
| Displacement code | 023 |
Series-specific model code
Original model: A17FO023/10NLWK0E81-0
Code coverage: Confirmed
Evidence profile: RE 91520 Issue 11.2015, A17FO Series 10
| Code segment | Evidence-bound meaning |
|---|---|
A17F |
Bent-axis fixed-displacement axial piston unit for commercial-vehicle application; 350 bar absolute nominal pressure; 400 bar absolute maximum pressure for no more than 5 s per single operating period and no more than 50 h accumulated over the total operating life, for mineral-oil operation. |
O |
Pump for open circuit. |
023 |
Size NG 23. |
10 |
Series 1, index 0. |
N |
Metric; port threads with profiled sealing ring according to DIN 3852. |
L |
Viewed on the drive shaft: counter-clockwise. |
W |
FKM, including two FKM shaft seal rings. |
K0 |
Special flange ISO 7653-1985 for trucks. |
E8 |
Splined shaft similar to DIN ISO 14 for trucks. |
1 |
Threaded ports A and S at rear. |
0 |
Standard version. |
Ordering-code meanings are limited to RE 91520 Issue 11.2015 for A17FO Series 10. They do not establish item-level performance or a complete installation decision.
Series Application
Commercial-vehicle high-pressure pump; PTO mounting context
Hydraulic system type: Axial piston fixed pump
Quote review notes: Confirm the complete order number, complete model code, nameplate photo when available, and required quantity.
Availability
Inquiry Only.
FAQ
Product FAQ
Is this the right record for my order number?
Use this record when the Order No or model code matches your nameplate. Send photos if the code is incomplete or written differently.
Can an alternate model code be used?
Yes, but the quote should still be checked against the primary order number and nameplate photo.
What should I send for quote review?
Send the complete order number, complete model code, nameplate photo when available, and required quantity.
