Product Identification
| Brand | Rexroth |
|---|---|
| Series | A2VK Series |
| Order No | R902043533 |
| Model | A2VK107MAGR1G1PE1-SO |
Rexroth A2VK Hydraulic Pump 鈥?Order No. R902043533
Rexroth A2VK catalog record for Order No. R902043533. Review the complete Model and nameplate before quote confirmation.
BrandRexroth
Order NoR902043533
ModelA2VK107MAGR1G1PE1-SO
Product NameR902043533 A2VK107MAGR1G1PE1-SO Hydraulic Pump
Technical TypeVariable Pump
SeriesA2VK Series
Product Overview
This record identifies Rexroth A2VK Order No. R902043533 and Model A2VK107MAGR1G1PE1-SO. The A2VK series is documented for pumping and metering polyurethane components; the complete ordering code and retained special suffix should be reviewed before quote confirmation.
Product Classification
| Category | Hydraulic Pumps |
|---|---|
| Product Type | Variable Pump |
| Series | A2VK |
Model Code Breakdown
Original Model: A2VK107MAGR1G1PE1-SO
Model code evidence status: documented body confirmed; special suffix requires confirmation
Evidence Profile: RE 94000/05.85 — A2VK Series 1 and 4 ordering-code profile
| Code Segment | Meaning |
|---|---|
A2VK |
Pump type: A2VK |
107 |
Size 107 |
MA |
Manual control |
G |
Closed circuit |
R |
Clockwise rotation, viewed on drive shaft |
1 |
Series 1 |
G |
Housed pump |
1 |
Built-on pressure relief valve |
P |
Parallel keyed shaft, DIN 6885 |
E |
Swivel movement to one side only |
1 |
Control on left, viewed on drive shaft |
-SO |
Contact us to confirm |
Evidence Gap: The retained special suffix is not defined in RE 94000/05.85; the eleven documented body positions remain confirmed.
Verified Series Facts
These are documented series-level facts within the matching evidence profile; they do not confirm every code position, the complete configuration or the performance of this individual Order No.
Evidence Scope: RE 94000/05.85 — A2VK Series 1 and 4 ordering-code profile
| Maximum geometric displacement for documented size 107 | 107.0 cm³/rev |
|---|---|
| Documented A2VK series nominal pressure | 250 bar |
| Documented A2VK series peak pressure | 315 bar |
Quote Review
Model code evidence status describes support for the displayed segment meanings. Final quotation still requires review of the complete order number, nameplate, model code and application; it does not guarantee product fit or a complete order configuration.
Keep -SO with the original Model and confirm this suffix during quote review.
One or more displayed code segments require confirmation.
FAQ
Product FAQ
What does the -SO suffix mean?
RE 94000/05.85 does not define the -SO suffix. Keep the suffix with the original Model and confirm it during quote review.
Does the breakdown confirm the complete pump configuration?
It explains the positions supported by the reviewed A2VK ordering-code document. The complete Order No., Model, retained suffix and nameplate still need to be checked together.
