Rexroth Order No. R902193560 is cataloged as A4VG model A4VG 71 DA1D7/32R-NZF02F001S for identification and quote review.
Product Details
| Brand | Rexroth |
|---|---|
| Series | A4VG Series |
| Order No | R902193560 |
| Model | A4VG 71 DA1D7/32R-NZF02F001S |
| Alternate search format | A4VG71DA1D7/32R-NZF02F001SSearch-format alias for this same order-number detail page; not a replacement, interchangeability or compatibility claim. |
Rexroth Order No. R902193560 is cataloged as model A4VG 71 DA1D7/32R-NZF02F001S in the A4VG Series. The selected evidence profile supports the displayed confirmed code positions; unresolved positions remain visible for confirmation. Review the complete order number, model and nameplate before quote review.
| Category | Hydraulic Pumps |
|---|---|
| Product Type | Axial piston variable pump |
| Series | A4VG Series |
Original Model: A4VG 71 DA1D7/32R-NZF02F001S
Reference displacement, Vg max (source order): 71 cm3/rev Theoretical values, rounded; profile-level references.
Evidence Profile: A4VG /32 Europe 2021
Model code evidence status: Some code positions are evidence-supported; remaining positions require confirmation.
| Code Segment | Meaning |
|---|---|
A4V |
Variable swashplate axial piston unit. |
G |
Pump for closed circuit. |
71 |
Geometric displacement Vg max: 71 cm3/rev (theoretical value, rounded). |
DA1 |
DA control family, version 1. |
D |
Pressure cut-off option code. |
7 |
DA control-valve position code; control-family dependencies still apply. |
/32 |
Series 3, index 2. |
R |
Direction of rotation, viewed on drive shaft: clockwise. |
N |
NBR seals with FKM shaft seal. |
Z |
Splined drive shaft Z. |
F |
Mounting flange F. |
02 |
Working-port arrangement 02. |
F |
With boost pump, configured filtration relationship applies. |
00 |
Without through drive. |
1 |
Pressure-relief valve code 1. |
S |
Standard filtration/supply code. |
(connector not recorded) |
Contact us to confirm |
Displayed meanings are limited to the selected A4VG evidence profile. A matched code position does not confirm the complete configuration, current orderability, availability, compatibility or interchangeability.
These are series-level facts within the matching evidence profile. They do not confirm every code position or the complete configuration of this individual Order No.
| Evidence Scope | RE-E 92003/2021-08-11 |
|---|---|
| Product Type | Variable swashplate axial piston pump |
| Design | Swashplate |
| Circuit | Closed circuit |
| Covered Sizes | 28 / 40 / 56 / 71 / 90 / 125 |
| Nominal Pressure | 400 bar |
| Maximum Pressure | 450 bar |
Displayed meanings apply only to evidence-supported code positions. Review the complete Order No., original Model, nameplate, required quantity and application before quotation; this does not confirm fit or the complete order configuration.
One or more displayed code positions require confirmation.
FAQ
No. It confirms only the displayed evidence-supported code meanings. Unresolved positions and the complete order configuration still require quote review.
It is a spacing or approved identifier-format alias for finding this same order-number detail page. It is not another product or a replacement, interchangeability or compatibility claim.
