Model G A4VSG 500 ‘DS’ M/22W-VZH10K02 is recorded under Rexroth A4VSG order R910941206. Additional alternate model text is retained as GA4VSG500‘DS’M/22W-VZH10K02 as a separate identification note.
Product Details
| Brand | Rexroth |
|---|---|
| Series | A4VSG Series |
| Order No | R910941206 |
| Model | G A4VSG 500 ‘DS’ M/22W-VZH10K02 |
| Alternate search format | GA4VSG500‘DS’M/22W-VZH10K02Search-format alias for this same order-number detail page; not a replacement, interchangeability or compatibility claim. |
Rexroth Order No. R910941206 is cataloged as model G A4VSG 500 ‘DS’ M/22W-VZH10K02 in the A4VSG Series. The model is reviewed as one pump segment. Evidence-supported code meanings are shown below; unresolved segments still require confirmation before quote review.
| Category | Hydraulic Pumps |
|---|---|
| Product Type | Axial piston variable pump |
| Series | A4VSG Series |
Original Model: G A4VSG 500 ‘DS’ M/22W-VZH10K02
Size codes (source order): 500
Evidence Profile: RE 92100 ed.03.2018, A4VSG Series 1x/3x
Model code evidence status: Partially confirmed; unresolved codes require confirmation.
| Code Segment | Meaning |
|---|---|
G |
Contact us to confirm |
A4VS |
Axial piston unit, variable swashplate design. |
G |
Pump for closed circuit. |
500 |
Size (NG) code listed in the approved A4VSG type-code table. |
‘DS’M |
Contact us to confirm |
/22 |
Contact us to confirm |
W |
Direction-of-rotation code listed in the approved A4VSG type-code table. |
- |
Type-code separator. |
V |
FKM sealing material / HFD operation. |
Z |
Splined shaft, DIN 5480. |
H |
ISO 3019-2 metric 8-hole mounting flange; availability is size-dependent. |
10 |
SAE flange working ports A and B, lateral on the same side, with metric fastening thread. |
K02 |
Contact us to confirm |
These are A4VSG series-level facts within the matching RE 92100 evidence scope. They do not confirm every pump segment or the complete configuration of Order No. R910941206.
| Series | 1x and 3x |
|---|---|
| Design | Axial piston unit, variable swashplate design |
| Circuit | Closed circuit |
| Sizes | 40 to 1000 |
| Nominal Pressure | 350 bar |
| Maximum Pressure | 400 bar |
Displayed meanings apply only to evidence-supported code segments. Review the complete order number, nameplate, model, quantity and application before quotation; this does not guarantee fit or a complete order configuration.
One or more displayed code segments require confirmation.
FAQ
No. It confirms only the displayed evidence-supported segment meanings. Unresolved codes and the complete configuration require quote review.
It is a search-format alias for this same order-number detail page. It is not a replacement, interchangeability or compatibility claim.
