Rexroth A7VO hydraulic pump catalog record for Order No. R902540551, Model A A7V O 500 LRDH2/63L-VPH02 -SO 17. Technical configuration requires confirmation; contact us with both identifiers.
| Brand | Rexroth |
|---|---|
| Series | A7VO Series |
| Order No | R902540551 |
| Model | A A7V O 500 LRDH2/63L-VPH02 -SO 17 |
| Model 1 | AA7VO500LRDH2/63L-VPH02-SO17Search-format alias for this same catalog record and Order No.; not a replacement or compatibility claim. |
This catalog record identifies Rexroth Order No R902540551 as model A A7V O 500 LRDH2/63L-VPH02 -SO 17 in the A7VO Series. The model code breakdown below separates evidence-supported segments from codes that still require confirmation. Check the complete order number, model code and nameplate before quote review.
| Category | Hydraulic Pumps |
|---|---|
| Product Type | Hydraulic Pump |
| Series | A7VO |
Original Model: A A7V O 500 LRDH2/63L-VPH02 -SO 17
Model code evidence status: partially confirmed
Evidence Profile: RE 92203/06.09
| Code Segment | Meaning |
|---|---|
A |
Contact us to confirm |
|
|
A7V |
Variable bent-axis axial piston unit |
|
|
O |
Pump for open circuit |
|
|
500 |
Nominal size 500 |
|
|
LRDH2 |
Power control with integrated fixed pressure control and hydraulic stroke limiter, initial Vg max, delta-p 25 bar |
/63 |
Series 6 index 3 |
L |
Counter-clockwise viewed on drive shaft |
-V |
FKM seals |
P |
DIN 6885 keyed shaft |
H |
Eight-hole mounting flange |
02 |
B or A and S ports at opposite side, SAE flange with metric fasteners |
|
|
-SO 17 |
Contact us to confirm |
These are documented series-level facts within the matching evidence profile; they do not confirm every code position, the complete configuration or the performance of this individual Order No.
| Series | Series 63 |
|---|---|
| Nominal Size | 500 |
| Product Type | Variable bent-axis axial piston pump |
| Circuit | Open circuit |
| Nominal Pressure | 350 bar |
| Maximum / Peak Pressure | 400 bar |
Model code evidence status describes support for the displayed segment meanings. Final quotation still requires review of the complete order number, nameplate, model code and application; it does not guarantee product fit or a complete order configuration.
One or more displayed code segments require confirmation.
FAQ
No. It confirms only the displayed evidence-supported segment meanings. The complete order number, nameplate, model code and application still require quote review.
It is a search-format alias for this same catalog record. It is not a separate product, replacement, interchangeability or compatibility claim.
