Order No. 014-70863-0 identifies this Parker Denison hydraulic motor in the M5A Series; the source model code is M5AF-025-1L04-B1M-0AP19M70863.
Product Details
| Brand | Parker Denison |
|---|---|
| Series | M5A Series |
| Order No | 014-70863-0 |
| Model | M5AF-025-1L04-B1M-0AP19M70863 |
| Alternate models | M5AF 025 1L04 B1M 0AP19M70863 |
| Also searched as | M5AF 025 1L04 B1M 0AP19M70863 / 014-70863-0 / 014708630 / M5AF-025-1L04-B1M-0AP19M70863 |
| Product type | Hydraulic Motor |
|---|---|
| Documented displacement | 25.0 cm3/rev |
Original model: M5AF-025-1L04-B1M-0AP19M70863
Code coverage: Evidence-supported meanings shown. Confirmation required for remaining configuration.
Evidence profile: M5AF field-level ordering-code profile (manual-evidence revision 6)
| Code segment | Evidence-bound meaning |
|---|---|
M5AF |
Series: M5AF. |
025 |
Documented displacement: 25.0 cm3/rev. |
1 |
Shaft: Taper shaft, non-SAE. |
L |
Direction of rotation: Counter-clockwise. |
04 |
End-cap type: side ports. |
B |
Design code: B (manufacturer design identifier). |
1 |
Seal: S1 BUNA-N seal class. |
M |
Connection: Four-bolt SAE flange with metric threads. |
0 |
Modification selection: 0. Contact us to confirm. |
A |
Option: Anti-starve-valve option. |
P |
Pressure-valve type: Proportional pressure valve. |
19 |
Pressure-setting code: 19. Contact us to confirm. |
M70863 |
Embedded special reference: M70863. Contact us to confirm. |
The parser follows the family-specific M5 ordering page. Each supplied shaft, rotation, end-cap, design, seal, connection, option, valve, pressure and special-reference field remains separate; unknown selections say Contact us to confirm.
Inquiry Only.
FAQ
Use this record when the Order No or model code matches your nameplate. Send photos if the code is incomplete or written differently.
Yes, but the quote should still be checked against the primary order number and nameplate photo.
Send the complete order number, complete model code, nameplate photo when available, and required quantity.
