Product Identification
| Brand | Rexroth |
|---|---|
| Series | A2FO Series |
| Order No | R902193821 |
| Model | A2FO80/61R-PAB05 |
Rexroth A2FO Hydraulic Pump 鈥?Order No. R902193821
Rexroth Order No. R902193821 is cataloged in the A2FO Series for identification and quote review.
BrandRexroth
Order NoR902193821
ModelA2FO80/61R-PAB05
Product NameR902193821 A2FO80/61R-PAB05 Hydraulic Pump
Technical TypeFixed-displacement bent-axis axial piston pump
SeriesA2FO Series
Product Overview
This catalog record identifies Rexroth Order No. R902193821 as Model A2FO80/61R-PAB05 in the A2FO Series. Use the model-code breakdown to review documented code positions, then check the complete Order No. and nameplate before quotation.
Product Classification
| Category | Hydraulic Pumps |
|---|---|
| Product Type | Fixed-displacement axial piston pump |
| Series | A2FO |
Model Code Breakdown
Original Model: A2FO80/61R-PAB05
Model code evidence status: partially confirmed
Evidence Profile: RA 91 401/08.97 page 2; RA 91 401/07.05 pages 2-3; RE 91401/06.2012 pages 2-3
| Code Segment | Meaning |
|---|---|
A2F |
ISO-version bent-axis axial piston unit with fixed displacement. |
O |
Pump for open circuit. |
80 |
Nominal size code; approximately the geometric displacement in cm3 per revolution. |
6 |
Series 6. |
1 |
Index 1 for nominal size 80. |
R |
Clockwise direction of rotation, viewed on the drive-shaft end. |
P |
Contact us to confirm |
A |
Splined shaft, DIN 5480. |
B |
4-bolt ISO mounting flange. |
05 |
SAE flange service ports A and B at side; SAE flange suction port S at rear. |
Evidence Gap: Only unsupported positions show Contact us to confirm; the product record remains available.
Verified Series Facts
These are documented series-level facts within the matching evidence profile; they do not confirm every code position, the complete configuration or the performance of this individual Order No.
Evidence Scope: RA 91 401/08.97 page 2; RA 91 401/07.05 pages 2-3; RE 91401/06.2012 pages 2-3
| Design | Fixed-displacement bent-axis axial piston pump |
|---|---|
| Circuit | Open circuit |
| Series | Series 6 |
| Standard-program sizes | 5, 10, 12, 16, 23, 28, 32, 45, 56, 63, 80, 90, 107, 125, 160, 180, 200, 250, 355, 500, 710, 1000 |
| NG 5 pressure | Nominal 315 bar; maximum 350 bar at series/size scope |
| NG 10-200 pressure | Nominal 400 bar; maximum 450 bar at series/size scope |
| NG 250-1000 pressure | Nominal 350 bar; maximum 400 bar at series/size scope |
Quote Review
Model code evidence status describes support for the displayed segment meanings. Final quotation still requires review of the complete order number, nameplate, model code and application; it does not guarantee product fit or a complete order configuration.
One or more displayed code segments require confirmation.
FAQ
Product FAQ
Does model code evidence confirm the complete order configuration?
No. It confirms only the displayed evidence-supported positions. The complete Order No., Model and nameplate still require quote review.
Why are Verified Series Facts not shown?
The preserved Model did not close one exact A2FO or AA2FO edition profile. Unsupported positions remain available for confirmation instead of inheriting another edition.
