Product Identification
| Brand | Rexroth |
|---|---|
| Series | A2FO Series |
| Order No | R902423855 |
| Model | A A2F O 182 /60L-VPB05 |
| Model 1 | AA2FO182/60L-VPB05Search-format alias for this same catalog record and Order No.; not a replacement or compatibility claim. |
Rexroth A2FO Hydraulic Pump 鈥?Order No. R902423855
Rexroth Order No. R902423855 is cataloged in the A2FO Series for identification and quote review.
BrandRexroth
Order NoR902423855
ModelA A2F O 182 /60L-VPB05
Product NameR902423855 A A2F O 182 /60L-VPB05 Hydraulic Pump
Technical TypeFixed-displacement bent-axis axial piston pump
Model 1AA2FO182/60L-VPB05
SeriesA2FO Series
Product Overview
This catalog record identifies Rexroth Order No. R902423855 as Model A A2F O 182 /60L-VPB05 in the A2FO Series. Use the model-code breakdown to review documented code positions, then check the complete Order No. and nameplate before quotation.
Product Classification
| Category | Hydraulic Pumps |
|---|---|
| Product Type | Fixed-displacement axial piston pump |
| Series | A2FO |
Model Code Breakdown
Original Model: A A2F O 182 /60L-VPB05
Model code evidence status: evidence-supported positions identified
Evidence Profile: RA 91 401/08.97 page 2; RA 91 401/07.05 pages 2-3; RE 91401/06.2012 pages 2-3
| Code Segment | Meaning |
|---|---|
AA2F |
SAE-version bent-axis axial piston unit with fixed displacement. |
O |
Pump for open circuit. |
182 |
Recorded size code; exact displacement and standard-program applicability require confirmation. |
6 |
Series 6. |
0 |
Recorded index code 0; standard-program size applicability requires confirmation. |
L |
Counter-clockwise direction of rotation, viewed on the drive-shaft end. |
V |
FKM (fluorocarbon) seals. |
P |
Parallel keyed shaft, DIN 6885. |
B |
4-bolt ISO mounting flange. |
05 |
SAE flange service ports A and B at side; SAE flange suction port S at rear. |
Evidence Gap: All displayed positions have a documented code meaning. The complete configuration still requires Order No. and nameplate review.
Verified Series Facts
These are documented series-level facts within the matching evidence profile; they do not confirm every code position, the complete configuration or the performance of this individual Order No.
Evidence Scope: RA 91 401/08.97 page 2; RA 91 401/07.05 pages 2-3; RE 91401/06.2012 pages 2-3
| Design | Fixed-displacement bent-axis axial piston pump |
|---|---|
| Circuit | Open circuit |
| Series | Series 6 |
| Standard-program sizes | 5, 10, 12, 16, 23, 28, 32, 45, 56, 63, 80, 90, 107, 125, 160, 180, 200, 250, 355, 500, 710, 1000 |
| NG 5 pressure | Nominal 315 bar; maximum 350 bar at series/size scope |
| NG 10-200 pressure | Nominal 400 bar; maximum 450 bar at series/size scope |
| NG 250-1000 pressure | Nominal 350 bar; maximum 400 bar at series/size scope |
Quote Review
Model code evidence status describes support for the displayed segment meanings. Final quotation still requires review of the complete order number, nameplate, model code and application; it does not guarantee product fit or a complete order configuration.
FAQ
Product FAQ
Does model code evidence confirm the complete order configuration?
No. It confirms only the displayed evidence-supported positions. The complete Order No., Model and nameplate still require quote review.
What is the alternate search format?
It is a search-format alias for this same Order No. and canonical page. It is not a replacement, interchangeability or compatibility claim.
