Rexroth Order No. R902456800 is cataloged in the A2FO Series for identification and quote review.
| Brand | Rexroth |
|---|---|
| Series | A2FO Series |
| Order No | R902456800 |
| Model | A A2F O 500 /60R-VZH11 -SO120 |
| Model 1 | AA2FO500/60R-VZH11-SO120Search-format alias for this same catalog record and Order No.; not a replacement or compatibility claim. |
This catalog record identifies Rexroth Order No. R902456800 as Model A A2F O 500 /60R-VZH11 -SO120 in the A2FO Series. Use the model-code breakdown to review documented code positions, then check the complete Order No. and nameplate before quotation.
| Category | Hydraulic Pumps |
|---|---|
| Product Type | Fixed-displacement axial piston pump |
| Series | A2FO |
Original Model: A A2F O 500 /60R-VZH11 -SO120
Model code evidence status: partially confirmed
Evidence Profile: RA 91 401/08.97 page 2; RA 91 401/07.05 pages 2-3; RE 91401/06.2012 pages 2-3
| Code Segment | Meaning |
|---|---|
AA2F |
SAE-version bent-axis axial piston unit with fixed displacement. |
O |
Pump for open circuit. |
500 |
Nominal size code; approximately the geometric displacement in cm3 per revolution. |
6 |
Series 6. |
0 |
Index 0 for nominal size 500. |
R |
Clockwise direction of rotation, viewed on the drive-shaft end. |
V |
FKM (fluorocarbon) seals. |
Z |
Splined shaft, DIN 5480. |
H |
8-bolt ISO mounting flange. |
11 |
SAE flange service ports A and B and suction port S at rear. |
SO120 |
Contact us to confirm |
Evidence Gap: Only unsupported positions show Contact us to confirm; the product record remains available.
These are documented series-level facts within the matching evidence profile; they do not confirm every code position, the complete configuration or the performance of this individual Order No.
Evidence Scope: RA 91 401/08.97 page 2; RA 91 401/07.05 pages 2-3; RE 91401/06.2012 pages 2-3
| Design | Fixed-displacement bent-axis axial piston pump |
|---|---|
| Circuit | Open circuit |
| Series | Series 6 |
| Standard-program sizes | 5, 10, 12, 16, 23, 28, 32, 45, 56, 63, 80, 90, 107, 125, 160, 180, 200, 250, 355, 500, 710, 1000 |
| NG 5 pressure | Nominal 315 bar; maximum 350 bar at series/size scope |
| NG 10-200 pressure | Nominal 400 bar; maximum 450 bar at series/size scope |
| NG 250-1000 pressure | Nominal 350 bar; maximum 400 bar at series/size scope |
Model code evidence status describes support for the displayed segment meanings. Final quotation still requires review of the complete order number, nameplate, model code and application; it does not guarantee product fit or a complete order configuration.
One or more displayed code segments require confirmation.
FAQ
No. It confirms only the displayed evidence-supported positions. The complete Order No., Model and nameplate still require quote review.
The preserved Model did not close one exact A2FO or AA2FO edition profile. Unsupported positions remain available for confirmation instead of inheriting another edition.
It is a search-format alias for this same Order No. and canonical page. It is not a replacement, interchangeability or compatibility claim.
