Rexroth order R902117156 corresponds to A4VG model A4VG90HWDL1/32R-NAF02F071F-S BR-BEIJ.
Product Details
This HydroCatalog record identifies Rexroth Order No. R902117156, original model A4VG90HWDL1/32R-NAF02F071F-S BR-BEIJ, in the A4VG Series. The A4VG /32 Europe 2021 reference supports the confirmed code positions below; any remaining positions require confirmation. Check the complete model and nameplate details before quote review.
| Brand | Rexroth |
|---|---|
| Series | A4VG Series |
| Order No | R902117156 |
| Model | A4VG90HWDL1/32R-NAF02F071F-S BR-BEIJ |
| Alternate models | A4VG90HWDL1/32R-NAF02F071F-SBR-BEIJ |
| Also searched as | A4VG90HWDL1/32R-NAF02F071F-SBR-BEIJ / R902117156 / A4VG90HWDL1/32R-NAF02F071F-S BR-BEIJ |
| Product type | Axial piston variable pump |
|---|---|
| Series Application | Closed-circuit hydraulic drive applications |
| Geometric displacement, Vg max | 90 cm3/rev |
Original model: A4VG90HWDL1/32R-NAF02F071F-S BR-BEIJ
Code coverage: Partial
Evidence profile: A4VG /32 Europe 2021
| Code segment | Evidence-bound meaning |
|---|---|
A4V |
Variable swashplate axial piston unit. |
G |
Pump for closed circuit. |
90 |
Geometric displacement Vg max: 90 cm3/rev (theoretical value, rounded). |
HW |
Hydraulic control with mechanical servo. |
D |
Pressure cut-off option code. |
L |
Neutral switch option for HW control. |
1 |
DA control-valve position code; control-family dependencies still apply. |
/32 |
Series 3, index 2. |
R |
Direction of rotation, viewed on drive shaft: clockwise. |
N |
NBR seals with FKM shaft seal. |
A |
Splined drive shaft A. |
F |
Mounting flange F. |
02 |
Working-port arrangement 02. |
F |
With boost pump, configured filtration relationship applies. |
07 |
Through-drive code 07. |
1 |
Pressure-relief valve code 1. |
F |
Filter in boost circuit. |
- |
Contact us for code confirmation |
SBR-BEIJ |
Contact us for code confirmation |
Code coverage is limited to the applicable A4VG Series 32 Europe 2021 or legacy AA4VG Series 32 reference. A matched code position does not confirm the validity, availability, or interchangeability of the complete configuration.
Closed-circuit hydraulic drive applications
Hydraulic system type: Axial piston variable pump
Quote review notes: Confirm the complete order number, complete model code, nameplate photo when available, and required quantity.
Inquiry Only.
FAQ
Use this record when the Order No or model code matches your nameplate. Send photos if the code is incomplete or written differently.
Yes, but the quote should still be checked against the primary order number and nameplate photo.
Send the complete order number, complete model code, nameplate photo when available, and required quantity.
