Rexroth A4VG R902137368 - A4VG56HD3DMT1/32R-NZC02F005D BR-BEIJ-3

Series-specific model code

Original model: A4VG56HD3DMT1/32R-NZC02F005D BR-BEIJ-3

Code coverage: Partial

Evidence profile: A4VG /32 Europe 2021

Code segment	Evidence-bound meaning
A4V	Variable swashplate axial piston unit.
G	Pump for closed circuit.
56	Geometric displacement Vg max: 56 cm3/rev (theoretical value, rounded).
HD3	Hydraulic control, pilot-pressure dependent.
D	Pressure cut-off option code.
M	Externally adjustable mechanical stroke limiter.
T	Stroking chamber pressure ports X3 and X4.
1	DA control-valve position code; control-family dependencies still apply.
/32	Series 3, index 2.
R	Direction of rotation, viewed on drive shaft: clockwise.
N	NBR seals with FKM shaft seal.
Z	Splined drive shaft Z.
C	Mounting flange C.
02	Working-port arrangement 02.
F	With boost pump, configured filtration relationship applies.
00	Without through drive.
5	Pressure-relief valve code 5.
D	Filtration/supply code D.
B	Contact us for code confirmation
R-BEIJ-3	Contact us for code confirmation

Code coverage is limited to the applicable A4VG Series 32 Europe 2021 or legacy AA4VG Series 32 reference. A matched code position does not confirm the validity, availability, or interchangeability of the complete configuration.
