Product Identification
| Brand | Rexroth |
|---|---|
| Series | A4VG Series |
| Order No | R909609024 |
| Model | AA4VG90HDD1/32R-NSF52F071D |
Rexroth A4VG Hydraulic Pump - Order No. R909609024
Rexroth Order No. R909609024 is cataloged as A4VG model AA4VG90HDD1/32R-NSF52F071D for identification and quote review.
BrandRexroth
Order NoR909609024
ModelAA4VG90HDD1/32R-NSF52F071D
Product NameRexroth A4VG R909609024 - AA4VG90HDD1/32R-NSF52F071D
Product TypeAxial piston variable pump
SeriesA4VG Series
Product Details
Product Overview
Rexroth Order No. R909609024 is cataloged as model AA4VG90HDD1/32R-NSF52F071D in the A4VG Series. The selected evidence profile supports the displayed confirmed code positions; unresolved positions remain visible for confirmation. Review the complete order number, model and nameplate before quote review.
Product Classification
| Category | Hydraulic Pumps |
|---|---|
| Product Type | Axial piston variable pump |
| Series | A4VG Series |
Model Code Breakdown
Original Model: AA4VG90HDD1/32R-NSF52F071D
Reference displacement, Vg max (source order): 90 cm3/rev Theoretical values, rounded; profile-level references.
Evidence Profile: AA4VG /32 legacy 2007
Model code evidence status: Some code positions are evidence-supported; remaining positions require confirmation.
Pump component 1
| Code Segment | Meaning |
|---|---|
AA4V |
Variable swashplate axial piston unit. |
G |
Pump for closed circuit. |
90 |
Geometric displacement Vg max: 90 cm3/rev (theoretical value, rounded). |
HDD1 |
Contact us to confirm |
/32 |
Series 3, index 2. |
R |
Direction of rotation, viewed on drive shaft: clockwise. |
N |
NBR seals with FKM shaft seal. |
S |
Splined drive shaft S. |
F |
Mounting flange F. |
52 |
Working-port arrangement 52. |
F |
With boost pump, configured filtration relationship applies. |
07 |
Through-drive code 07. |
1 |
Pressure-relief valve code 1. |
D |
Filtration/supply code D. |
Displayed meanings are limited to the selected A4VG evidence profile. A matched code position does not confirm the complete configuration, current orderability, availability, compatibility or interchangeability.
Verified Series Facts
AA4VG /32 legacy 2007
These are series-level facts within the matching evidence profile. They do not confirm every code position or the complete configuration of this individual Order No.
| Evidence Scope | RA 92 003/09.07; legacy AA4VG scope |
|---|---|
| Legacy Scope | AA4VG Series 32 legacy profile |
| Design | Variable swashplate axial piston pump |
| Circuit | Closed circuit |
| Covered Sizes | 28 / 40 / 56 / 71 / 90 / 125 / 180 / 250 |
Quote Review
Displayed meanings apply only to evidence-supported code positions. Review the complete Order No., original Model, nameplate, required quantity and application before quotation; this does not confirm fit or the complete order configuration.
One or more displayed code positions require confirmation.
FAQ
Product FAQ
Does the model code breakdown confirm the complete order configuration?
No. It confirms only the displayed evidence-supported code meanings. Unresolved positions and the complete order configuration still require quote review.
